ISO 7093-1, Plain washer, 3,5 mm, A2, 200 HV

Price

€15.47

per 100 piece(s)

Deliverable (3-4 weeks)
Article number 527093035
Material Stainless steel
Quality A2, 200 HV
Coating pln
Suitable for screw diameter M 3.5
Inner diameter 3,7 mm
Outer diameter 11 mm
Thickness 0,8 mm
Article variant

Your order:

Create item data sheet

Product details

Large Series. Product grade A.

Outer diameter 11  mm
Inner diameter 3.7  mm
Norm ISO 7093 1
EAN/GTIN None

Remarks

Standard DIN 9021 was withdrawn and replaced by ISO 7093-1. In ISO 7093-1 the nominal sizes are based on thread diameter, in DIN 9021 on hole diameter.
